Background

Many different problems can prevent a BEAST2 analysis from starting, from technical and file issues to incompatibilities in the model setup. Most analyses setup in BEAUti will run out-of-the-box, but as soon as you start tinkering with prior distributions and initial values the chance of running into an issue starts rising. This shouldn’t act to discourage you from editing the default priors and initial values! You should always consider all priors and initial values and edit them if the default values don’t make sense for your analysis.

In this tutorial, we will show some examples of common issues and learn how to diagnose and fix them. Most of the initialization issues you are likely to encounter should be similar to one of the issues presented below. The more issues you encounter and fix the easier it will become to solve issues and get your BEAST analysis to start!

Programs used in this Exercise

BEAST2 - Bayesian Evolutionary Analysis Sampling Trees 2

BEAST2 (http://www.beast2.org) is a free software package for Bayesian evolutionary analysis of molecular sequences using MCMC and strictly oriented toward inference using rooted, time-measured phylogenetic trees. This tutorial is written for BEAST v2.7.x (Bouckaert et al., 2014; Bouckaert et al., 2019).

BEAUti2 - Bayesian Evolutionary Analysis Utility

BEAUti2 is a graphical user interface tool for generating BEAST2 XML configuration files.

Both BEAST2 and BEAUti2 are Java programs, which means that the exact same code runs on all platforms. For us it simply means that the interface will be the same on all platforms. The screenshots used in this tutorial are taken on a Mac OS X computer; however, both programs will have the same layout and functionality on both Windows and Linux. BEAUti2 is provided as a part of the BEAST2 package so you do not need to install it separately.

Any programmer-friendly text editor

We will need to perform some manual edits on the XML files produced by BEAUti, for which we’ll need a text editor. XML files can be opened by any text editor, but it’s best to use one designed for programmers as these include nice features such as syntax highlighting, which makes the code more reader-friendly. Sublime Text is a good option which is available for MacOS, Windows and Linux. Other options include Notepad++ (Windows), Emacs (any platform) or VSCode (any platform).

Practical: Getting BEAST2 to start

The Data

The data used in this tutorial is an alignment of genetic sequences for the interphotoreceptor retinoid-binding protein (irbp), and a morphological character matrix. Both alignments contain data for 8 extant and 14 fossil bear species. To illustrate different issues we have created several XML files using this dataset, each with a different initalization issue, available on the left-hand panel, under the heading XML.

Packages

Examples in this tutorial require the SA (Sampled Ancestors) package to be installed.

Launch BEAUti, then open the BEAST2 Package Manager by navigating to File > Manage Packages (Figure 1).

The SA package may already be installed. Otherwise, install it by doing the following.

Install the SA package by selecting it and clicking the Install/Upgrade button (Figure 2).

Next, uninstall the MM package by selecting it and clicking the Uninstall button (Figure 3).

The reason for uninstalling the MM package will become clear later. Note that uninstalling MM will also necessitate uninstalling any installed packages that depend on it. Please remember to reinstall these packages after finishing this tutorial! If the MM package wasn’t installed then clicking uninstall will have no effect.

BEAUti needs to be closed for the newly installed packages to be loaded properly.

Close the BEAST2 Package Manager and BEAUti.

Common issue #1: Class could not be found

Download the BEAST2 input file issue1.xml.

• Open BEAST2 and select the file issue1.xml as input file.
• Start the run with the Run button. You should get an error message, as shown in Figure 4.

This error means that BEAST2 could not identify one of the components of the analysis in the XML file. We have helpfully highlighted the important part of the error message in Figure 4. It shows which component is unidentified, in this example the class morphmodels.evolution.substitutionmodel.LewisMK, as well as the program’s closest guess for what the component could be, here beastlabs.inference.ML. BEAST2 also shows you roughly where the reference to the missing component was found within the hierarchical structure of the XML file (here it is the substitution model, inside the site model, inside the tree likelihood, and so on).

There are two main causes for this error:

• An error was introduced in the component name when editing the XML file manually. In this case, you simply need to edit the XML file to use the correct name.
• The BEAST2 package which contains this component is not installed. In this case, you need to identify which package is missing. If the file was produced by BEAUti, it should contain a list of required packages in the first line of the file.

In this example, we have not edited the XML manually, so we conclude that we are missing a package. If we open the XML file in a text editor, we can see the list of required packages (separated by colons) in the XML header on the first line.

required="BEAST.base v2.7.4:SA v2.1.1:MM v1.2.1"

BEAST.base is always installed and we just installed SA. Thus we are missing the MM package which contains morphological substitution models (earlier we made sure that this package is uninstalled so that this XML file would not initialize). In fact, because the required packages are listed in the XML file, BEAST2 also detected the missing package and reported it with the error message: The following package is required, but is not available: MM v1.2.1.

However, keep in mind that if the XML file was manually edited then it is possible that not all required packages are listed in the XML header. In these cases you have to examine the missing component error to fix the issue.

Open issue1.xml in a text editor and remove the MM package from the requirements. Save the file and run it in BEAST2.

Did the error message change?

When the required packages are not listed in the XML file it can sometimes be tricky to figure out which package to install, because not all packages have self-explanatory names and the Java classpath of the missing component doesn’t always contain the package name (as is the case here). In this case we can guess that the missing component (morphmodels.evolution.substitutionmodel.LewisMK) has something to do with morphological models. In the BEAST2 package manager there are short descriptions of each package on the right. For MM the description reads “Enables models of morphological character evolution.” We can also click on the link icon to be taken to the code repository for the MM package, where we can easily verify that morphmodels.evolution.substitutionmodel.LewisMK is indeed included in it (within the src/ directory).

There are still times when this strategy won’t work (the package is messy, contains many different types of models, or the package may not even be available on the default BEAST2 package repository). In such cases you can try examining the source of the XML file (e.g. a tutorial or a publication) or simply do an online search for the name of the missing component. For instance, the MM package repository is one of the top results in a Google search for morphmodels.evolution.substitutionmodel.LewisMK.

Following the same process as for the SA package, open the BEAST2 Package Manager in BEAUti and install the MM package.

Close and reopen BEAST2 and run the file issue1.xml again, checking that it now initializes and runs.

Common issue #2: Output files already exist

Download the BEAST2 input file issue2.xml in the same folder as issue1.xml.

• Open BEAST2 and select the file issue2.xml as input file.
• Start the run with the Run button. You should get an error message, as shown in Figure 5.

This error means that BEAST2 is attempting to overwrite a .log or .tree file that already exists, as explained in the message Trying to write file bears.log but the file already exists. By default, overwriting files is not permitted in order to avoid accidentally losing data. If BEAST2 is run in interactive mode from the command line, for instance on your local machine, it offers you the possibility to continue the analysis, by typing Y to overwrite the files. However, if BEAST2 is run on a computing cluster, it will simply stop when encountering this issue.

To solve this problem, there are three possibilities:

• If the intention is to overwrite the existing files, select the overwrite option from the dropdown menu in the BEAST2 launcher (see Figure 6) or use the -overwrite option in the command-line interface.

• If the intention is to resume a run, i.e. to append to the existing files, select the resume option from the dropdown menu in the BEAST2 launcher (see Figure 7) or use the -resume option in the command-line interface.

• If you would like to create new files, either move the original files, move the XML file, or change the names of the .log and .tree files in the new analysis.

Open BEAUti and load the file issue2.xml.

• In the MCMC panel, expand the options for the tracelog by clicking on the arrow to the left. Change the File Name to bears_longer.log.
• Do the same for the treelog and change the File Name to bears_longer.trees.
• Save the file issue2.xml. Run it in BEAST2 again, and check that it now works.

This issue may seem simple and straightforward, but it has been the cause of countless hours of delays and lost computing time!

To make your life easier and avoid accidentally overwriting output files you can use the variables $(filebase), $(seed) and $(tree) in the names for the .log and .tree files. When you run the analysis $(filebase) will be replaced by the name of the XML file (without the .xml extension), and $(seed) by the random number seed (useful for reproducing exactly the same analysis). The $(tree) variable can be used to label different .tree files when an analysis contains more than one tree. Since BEAST 2.7 the default .log filename is $(filebase).log and the default .tree file name is $(filebase)-$(tree).trees.

Common issue #3: Could not find a proper state to initialize

Troubleshooting a simple parameter issue

Download the BEAST input file issue3a.xml.

• Open BEAST2 and select the file issue3a.xml as input file.
• Start the run with the Run button.

You should get an error message, as shown in Figure 8.

The inference failed to start because a good initial state could not be found, as explained by the error message (Could not find a proper state to initialise. Perhaps try another seed). This issue is much more complex to diagnose than the previous ones, as it can be caused by many different parts of the analysis configuration. The suggestion to try another seed is not a very good one and we will come back to it in the “Number of initialization attempts” section below.

Above the error message BEAST2 traces through its attempt to calculate an initial value for the posterior. We can use this trace to figure out which model component is responsible for the issue. Remember that the posterior is given by Bayes’ formula,

where $\theta$ is a vector of all the model parameters and $D$ is the data, here consisting of the genetic data, $D_G$ and the morphological data, $D_M$. In the equation above $P(D \mid \theta)$ is the likelihood and $P(\theta)$ the prior.

In our model we are estimating the following parameters:

• Tree, $\mathcal{T}$
• Fossilized birth-death (FBD) model:
  • Diversification rate, $\lambda$
  • Turnover, $\gamma$
  • Sampling proportion, $p$
  • Origin time, $t_0$
• HKY nucleotide substitution model:
  • Transition/transversion ratio, $\kappa$
  • Nucleotide equilibrium frequencies, $\Pi = (\pi_A, \pi_C, \pi_G, \pi_T)$
• Lewis MK morphological trait substitution model:
  • Relative mutation rate, $\phi$
• Strict clock models:
  • Nucleotide substitution rate, $\mu_G$
  • Morphological trait substitution rate, $\mu_M$

Thus, we can write the posterior as,

We assume that the genetic and morphological likelihoods are independent and that all of the other model parameters are independent of each other (except for the tree, which is generated by the FBD parameters), so we can factorise the likelihood and the prior. We also don’t need to calculate $P(D)$ when using MCMC to estimate posterior distributions, so what BEAST2 actually calculates is,

In this nasty expression $P(\mathcal{T} \mid \lambda, \gamma, p, t_0)$ is the tree prior (here the fossilized birth-death model), which is the only part of the prior that depends on other parameters. You can find all the model parameters by loading the XML file into BEAUti, or by locating the <state> section in the XML file.

For computational reasons BEAST2 calculates log probabilities, which means values of $-\infty$ correspond to prior or model probabilities of 0. When initialising, BEAST2 attempts to calculate $P(\theta \mid D)$. To do so, it recursively attempts to calculate all of the parts of the posterior, until it reaches a density that can be evaluated without calculating anything else. Thus it firsts calculates all the parameter priors (because they don’t depend on anything else), then the tree prior (which depends on some parameters), then the likelihoods and finally the posterior. To find the root of the problem we have to trace through our posterior calculation and find the component furthest downstream with a value of $-\infty$. When tracing through the error message above we see three parts of the model returned $-\infty$:

• P(posterior) = -Infinity (was -Infinity)
• P(prior) = -Infinity (was -Infinity)
• P(ClockPrior.c:bears_irbp_fossils) = -Infinity (was -Infinity)

The likelihoods returned NaN (not a number), which means BEAST2 crashed before they could be calculated (BEAST2 stops as soon as a model component returns $-\infty$). Thus, we can conclude that the model most likely failed when calculating the prior of the clock rate of the genetic alignment, $\mu_G$ above.

To inspect the parameter and find the issue, we will first load the file into BEAUti.

Open BEAUti and load in the issue3a.xml file by navigating to File > Load.

• Switch to the Priors panel.
• Click on the arrow left of the clockRate.c:bears_irbp_fossils to see the details of this prior (Figure 9).

We can see that the clock rate prior was changed from the default, which is a uniform distribution between 0 and infinity, to a uniform distribution between 0 and 0.5. In general, changing this default prior is a good idea, as the default is extremely vague, places far too much weight on very large and unrealistic values and is thus not an accurate description of our prior knowledge.

Whenever we change a prior distribution from the default and especially when setting priors with hard bounds (e.g. a uniform or Beta distribution), we need to make sure that the initial value of the parameter still falls within the bounds of the distribution. For each parameter, the initial value is shown in the box to the right, as initial = [x] [min, max]. Here x indicates the initial value and min and max the range of possible values for the corresponding parameter.

Check the initial value of the clockRate.c:bears_irbp_fossils parameter in the box to the right of the parameter. We can see that the box reads initial = [1.0].

The initial value of the clock rate is set to 1.0, which is outside the bounds of the prior for this parameter. This is why the initialization failed.

In the Priors panel, click on the initial = [1.0] box right of the clockRate.c:bears_irbp_fossils parameter.

• Change the initial value in the Value box to 0.01 (Figure 10).
• Click on OK to close the box.
• Save the updated configuration as issue3a_fixed.xml by navigating to File > Save As.>
• Open BEAST2 and select issue3a_fixed.xml as the input file.
• Start the run with the Run button. It works now!

Using this procedure to trace through the calculation of the posterior you can always identify which model component is causing an initialization issue. Usually simple issues like initial values are the cause, but there are times when things are more complex.

Topic for discussion

In the XML file issue3a.xml, is there a prior for the relative mutation rate in the Lewis MK model, $\phi$?

It is not shown in the initialization trace Figure 8, which means no explicit prior was set for this parameter. Is this a problem? If no prior distribution is set in the XML file, what prior is used for the parameter?

Answer

If no prior is set for a parameter the implicit prior becomes a uniform distribution between the parameter bounds. In the case of the mutation rate (called mutationRate.s:bears_morphology2 in the XML file), no bounds are set either, so it inherits the default bounds of a real parameter in BEAST2, which is between negative and positive infinity.

In this case it doesn't make any difference. Although the parameter is estimated, the Delta exchange operator that acts on it constrains it to always be equal to one (it would probably have made more sense to just fix the parameter though).

In general, an unbounded uniform prior is a bad idea for most parameters for exactly the same reasons it is a bad choice for the clock rate. More importantly, "hidden" priors like these are a problem when doing model selection. An unbounded uniform prior is an improper prior (there exists no normalising constant that can make it integrate to 1, so it integrates to infinity). Improper priors can cause issues with model selection if the posterior then also integrates to infinity. In general it's impossible to know if using an improper prior will lead to a proper posterior, so it is recommended to not use improper priors (we can only know if the posterior is proper if we can analytically integrate it, which is usually not the case for BEAST models). It is always possible to set some sensible parameter bounds, so we can always make all of our priors proper.

Finding out if there are "hidden" priors in your model is more complex, especially when the BEAUti template for a model doesn't explicitly initialize priors for all model parameters. You can navigate to the Initialization panel in BEAUti (click View > Show Initialization panel to display it) to check if all model parameters also have prior distributions set (by comparing with the Priors panel), but it is unfortunately not possible to add a missing prior from BEAUti. If you've identified such a model parameter then you would need to add the prior by manually editing the XML file. It is also a good idea to contact the package developers, so they can address the issue in future releases.

Troubleshooting incompatibilities between model components

In the example above the incompatibility was just within one parameter that was out of the bounds of its prior. When one model parameter appears in multiple model components, incompatibilities between different model components can lead to the posterior evaluating to negative infinity. This most often involves the tree, which appears in many model components. If, in addition, MRCA priors with hard bounds or offsets are set, or the starting tree is fixed, the probability for an incompatibility is much higher.

One particular example occurs with birth-death models where the origin parameter is estimated (such as the BDSKY, BDMM or FBD models).

Download the BEAST2 input file issue3b.xml.

• Open BEAST2 and select the file issue3b.xml as input file.
• Start the run with the Run button. You should get an error message, as shown in Figure 11.

While this is a validation issue, the error message is different to the example above. Here the message (Initial value of origin (100.0) should be greater than initial root height (125.1)) indicates clearly what is going on: we have specified an origin parameter with an initial value which is incompatible with the initial tree (by definition the origin should be larger than the height of the tree).

Unfortunately, while it is straightforward to create an XML file with this error in BEAUti, it cannot be loaded into BEAUti again for editing (give it a try). This is because BEAUti does more than simply write XML code to files. While editing the XML file, BEAUti also instantiates the model (using the same code that BEAST2 uses to run the model). This is done to ensure that BEAUti only produces XML files containing BEAST2 analyses with the correct syntax. Similarly, when loading an XML file into BEAUti, the model is instantiated. If doing so returns any errors, BEAUti cannot load the XML file. This would be the case if, for example the XML file contains syntax errors, or it refers to classes in packages that are not installed. In this particular case, the FBD model checks that the initial value of the origin parameter is greater than the height of the starting tree. Since this is not the case here, the model throws an error and BEAUti fails to load the XML file. To correct this error we can either recreate the whole XML file from scratch in BEAUti, or quickly edit it in a text editor.

Open the issue3b.xml file in a text editor.

• Look for where the parameter originFBD.t:bears is defined in the XML file and examine its initial value. (It is defined within the <state> block)
• The initial value is the unlabelled value just before the closing </parameter> tag.
• Look for the root prior root.prior and examine its distribution.
• The root prior’s distribution is inside the prior, the <distribution id="prior" spec="CompoundDistribution"> block, and within the prior is inside the <distribution id="root.prior" block, after the taxon set defining all the taxa included in this MRCA prior.
• Look in particular at the values for the offset, M and S parameters.

The origin parameter configuration is:

<parameter id="originFBD.t:bears" spec="parameter.RealParameter" lower="0.0" name="stateNode">100.0</parameter>

And the root prior distribution is set up like this:

<LogNormal id="LogNormalDistributionModel.9" name="distr" offset="125.0">
     <parameter id="RealParameter.92" spec="parameter.RealParameter" estimate="false" name="M">2.0</parameter>
     <parameter id="RealParameter.93" spec="parameter.RealParameter" estimate="false" lower="0.0" name="S" upper="5.0">0.5</parameter>
</LogNormal>

We can see that the distribution for the root prior has an offset of 125.0, meaning that the root of the tree will always be greater than this value. However the initial value of the origin parameter was left to the default, which is 100.0. This is the source of the error reported by BEAST2. Thus we need to change the value of the origin to be compatible with our starting tree.

• In the text editor, look for the parameter originFBD.t:bears and change its initial value from 100.0 to 150.00.
• Save the updated configuration as issue3b_fixed.xml.
• Open BEAST2 and select issue3b_fixed.xml as the input file.
• Start the run with the Run button. It works now!

Here the incompatibility stemmed from us setting a root prior with an offset. This scenario is a little contrived, however setting a root prior is not the only way this issue can occur! It can also happen when using a user-specified starting tree, for instance a tree from a Newick string. In such a case the origin parameter needs to be compatible with the specified tree, i.e. the initial value of the origin needs to be higher than the root of the Newick tree. Finally, it is also entirely possible for this issue to occur even when using a default randomly initialized tree.

Some other common cases where inconsistencies between model components can lead to initialization failures are:

• Setting multiple (reciprocally incompatible) MRCA priors on different nodes in the tree.
• Setting monophyly constraints on the tree and supplying a starting tree incompatible with these constraints.
• When an initial tree is specified for a structured analysis that is incompatible with the initial parameter values of the migration model.
• When the initial values for rates are set to 0, for instance setting the initial value of the sampling rate (of a birth-death model) to 0 means that it is impossible to have observed any samples, so every tree has a probability of 0 under the model.

Some more common model incompatibilities are also listed here.

Troubleshooting a complex parameter issue

Download the BEAST input file issue3c.xml.

• Open BEAST2 and select the file issue3c.xml as input file.
• Start the run with the Run button. You should get an error message, as shown in Figure 12.

As before, BEAST2 could not find a valid state to start the inference. This time there are finite values for all of the simple parameter priors, meaning that all of the initial values fall within the prior bounds. The two exceptions are the FBD tree prior, which reads P(FBD.t:bears) = -Infinity and an MRCA prior on the root of the tree, which reads P(root.prior) = NaN, meaning it was not evaluated before BEAST2 crashed. Thus, we can conclude that the issue likely has something to do with the calculation of the FBD density. The FBD prior is a tree prior, and depends on the tree as well as several other parameters, so there are several possible causes for the issue:

• An issue with the initial tree: the inference will not start if the initial tree is impossible under the specified tree model or MRCA constraints. By default, most analyses use a simple coalescent model to simulate a random initial tree that respects all MRCA constraints. However, with more complex models, or incompatible MRCA priors, the simulation process can fail to find a good tree. Similarly, when there are additional constraints on the tree that are not encoded in MRCA priors (as with the origin parameter in the example above), the simulated tree can also be incompatible. In such cases the simulation either needs to be fine-tuned to satisfy the constraints, or a valid initial tree should be provided to the analysis.
• An issue with the initial parameter values: if the initial values set in the analysis are very far from plausible, the resulting density of the model will be extremely small. Because of the limitations of floating point arithmetic used by computers, numbers with very large magnitudes get approximated to positive or negative infinity and numbers with very small magnitudes to zero. That means for very improbable parameter combinations, the density of a model, $P(\theta) \approx 0$. Usually, calculations are done in logspace to alleviate this effect, however for extremely unlikely parameter combinations we will have $\log P(\theta) \approx -\infty$. Most of the parametric prior distributions available in BEAST2 only tend to 0 as the parameter tends to infinity, making it very unlikely to encounter numerical underflow issues with these distributions. However, more complex distributions, like tree priors, have complex, high-dimensional density landscapes and it is entirely possible that a parameter combination that works for one model evaluates to negative infinity for a related model.
• A bug in the density calculation: BEAST2 packages can contain calculation issues which have remained undetected so far (especially if they only appear under very specific circumstances). Such bugs should be reported to the package developers. However, this is unlikely in our case, as the FBD model has been extensively tested and used in the past, and our analysis setup is similar to previous analyses.

To inspect the initial values and find the issue, we will first load the file into BEAUti.

Open BEAUti and load in the issue3c.xml file by navigating to File > Load.

The starting tree can be found in the Starting tree panel, which is hidden by default.

Open the Starting tree panel by navigating to View > Show Starting tree panel. Switch to the Starting tree panel.

As we can see in Figure 13, the initial tree in this analysis is set to a Newick tree, chosen by the user. The Newick box gives the full Newick string, which we could use to inspect the tree in an other program. This string can also be copied directly from the XML file. First, we will check if this tree is compatible with the tree constraints set in the Priors panel.

Switch to the Priors panel. Click on the arrow left of the root.prior to see the details of this prior (Figure 14).

The only constraint set on the tree is a prior on the age of the root, which we can see in the Priors panel. By checking the details, we can see that this is a wide lognormal prior, with the 5% quantile of the prior at 206 Ma and the 95% quantile at 437 Ma (in this analysis branch lengths are in millions of years). Normally, a single lognormal MRCA prior will not be incompatible with any tree, since it is defined across all positive real numbers and only approaches 0 for parameter values approaching infinity. However, this particular prior also has an offset of 25 Ma set. That means any tree with a root height less than 25 Ma will be incompatible with this prior.

Let’s import our starting tree in Icytree to check if the root age is compatible with the prior.

Open Icytree (https://icytree.org/) in a web browser.

• Copy the Newick string from the Starting tree panel or from the XML file. Make sure that you copy the whole string, up to the semi-colon at the end (it may be easiest to double or triple click on it to select everything).
• In the IcyTree browser window click File > Enter tree directly.
• Paste the copied Newick string and press Done to display the tree in IcyTree.

By hovering over the root node of the starting tree, we can see that its age is set to 417.2 Ma, which is consistent with the root prior set in the analysis.

Next, we will inspect the initial values of the parameters of the FBD model, found in the Priors panel in BEAUti. The FBD model has 3 parameters: the diversification rate, the turnover and the sampling proportion. We can see that the initial diversification rate is 1.0, the initial sampling proportion 0.5 and the initial turnover 0.5. These are the default values of these parameters, but they may not be adapted to all datasets. In particular, a diversification rate of 1.0/My is a very high value - since our starting tree is more than 400 My old, it means that we would expect about $\exp(400 \times 1.0) \approx 5 \times 10^{173}$ extant species (as opposed to the 8 extant bears we actually have). Having a very implausible starting value for the diversification rate could explain the failure we observed earlier when calculating the likelihood of the FBD model, so we will change it to a more realistic value of 0.01. This leads to the much more reasonable $\exp(400 \times 0.01) \approx 55$, still more than observed, but not so unlikely that the log density would evaluate to negative infinity.

In the Priors panel, click on the initial = [1.0] box right of the diversificationRateFBD parameter.

• Change the initial value in the Value box to 0.01 and click on OK to close the box (Figure 15).
• Save the updated configuration as issue3c_fixed.xml by navigating to File > Save As.
• Open BEAST2 and select issue3c_fixed.xml as the input file.
• Start the run with the Run button. It works now!

Topic for discussion

We investigated three model components in the example above, the MRCA prior, the initial tree and the FBD tree prior.

We finally found that the initial parameter combination of the FBD tree prior was very unlikely, specifically the diversification rate was incompatible with the tree height. If we had not specified an MRCA prior or an initial tree, would we still have encountered the initialization error?

Try removing the MRCA prior and changing the initial tree back to a randomly simulated tree in BEAUti to investigate this question!

Using a different seed or increasing the number of initialization attempts

If there are no obvious incompatibilities in the analysis setup, it is possible that the problem is simply due to bad luck rather than a fundamental problem with the setup. During initialization some model components are randomly initialized. In a standard analysis this is just the starting tree, but could also be other model components, depending on the models and packages used. It is possible that the random starting tree is just extremely unlikely under the model configuration and causes initialization to fail. This is rare, but it can happen with complex configurations or with packages and models that are still under development.

For randomly initialized model components the random number seed is very important and if a specific seed was used to run the analysis then changing it may indeed help, as suggested by BEAST2 (Figure 8). However, if no seed is provided to BEAST2 then the seed is itself random and a different seed is used each time the analysis is attempted.

To save time rerunning the same analysis with many different seeds, BEAST2 by default tries to initialize an analysis 10 times before giving up, but it is possible to increase the number of attempts.

Open BEAUti and load in the issue3b.xml file by navigating to File > Load.

• Switch to the MCMC tab.
• The number of initialization attempts is controlled by the Num Initialization Attempts setting, shown in Figure 16.

Note that changing this setting will never help if the analysis contains incompatibilities (or any of the other issues above). In the case of the issue3a.xml file, for instance, the starting value of the clock rate is outside of the bounds of the corresponding prior, so initialization will always fail regardless of how many attempts are performed. Similarly, if no model components are randomly initialised (e.g. a fixed starting tree is used) and there is an initialization issue, then no number of initalization attempts will solve the issue.

Topic for discussion

If no model components are randomly initialised does the random number seed still have an effect on the analysis?

Answer

Yes, it still makes a difference! Although each analysis will start from the exact same point in the posterior landscape, the random number seed is important for initializing the operators, used to make proposals in the MCMC run. Thus, each random number seed will result in a unique trajectory followed across the posterior. However, it is a good idea to initialize at least some model components randomly, as always starting with the same initial values can mean we get stuck in a local optimum. (Keep in mind that in the case of large trees a random initial tree will take extremely long to burn in and for pragmatic reasons a "good" initial tree is often used).

Common issue #4: Validation error when parsing XML file

Download the BEAST input file issue4.xml and issue4_working.xml.

• Open BEAST2 and select the file issue4.xml as input file.
• Start the run with the Run button. You should get an error message, as shown in Figure 17.

Here the run failed to start because the XML file could not be parsed, as explained by the error message Error 110 parsing the xml input file. Thankfully the error message tells us exactly where the error happened (<log id=’ORCRatesStat.c:bears_morphology’ spec=’beast.base.evolution.RateStatistic’>) and what the issue is (Input ‘tree’ must be specified.). If we open the issue4.xml file and look for ORCRatesStat.c:bears_morphology, we can see that line 771 corresponds to the error message and reads as follows:

<log id="ORCRatesStat.c:bears_morphology" spec="beast.base.evolution.RateStatistic" branchratemodel="@OptimisedRelaxedClock.c:bears_morphology"/>

By comparing to a previous (working) analysis in the file issue4_working.xml, we can see that the correct configuration should be (line 733):

<log id="ORCRatesStat.c:bears_morphology" spec="beast.base.evolution.RateStatistic" branchratemodel="@OptimisedRelaxedClock.c:bears_morphology" tree="@Tree.t:bears"/>

As the error message told us, the tree element of the configuration is missing in the non-working XML file, so we need to add it back in.

Open the file issue4.xml in a text editor.

• Modify line 771 of the file to add the tree="@Tree.t:bears" element. Save the file as issue4_fixed.xml.
• Open BEAST2 and select the file issue4_fixed.xml as input file.
• Start the run with the Run button. Now it works!

XML parsing errors usually occur when the XML file has been manually edited and parts of the configuration have been accidentally deleted or modified. This is why it’s important to always keep a copy of the original XML file or use version control when making manual edits, as this provides an easy way to compare edits to a working configuration. Loading, saving and re-loading complex configurations into BEAUti repeatedly can also lead to parsing issues, although if this happens it is a bug and should be reported to the package developers (for instance by opening an issue on the package repository, findable in the BEAST2 package manager). In general, if an XML parsing error occurs in a file which was generated entirely through BEAUti, then this bug should be reported to the package developers.

Debugging BEAST2 XML (optional)

Unless you know your way around the BEAST2 source code it can be difficult to know how to manually edit the components in an XML file. In the example above, we already had a previous, working analysis and could use that to debug the issue. But if we didn’t have it, it may have taken us much longer to figure out how to specify the tree for the rate statistic component.

Fortunately, all of the components are documented in the BEAST2 XML manual at http://www.beast2.org/xml/index.html. If we search for RateStatistic in the left-hand panel, we see that tree is a required input (Figure 18).

However, there is a problem. The online manual is for BEAST v2.6.7 and may be outdated for some components. More importantly, the online documentation only contains components in the BEAST2 core and nothing in any of the packages we installed. Luckily we can easily generate the documenation for the version of BEAST2 and all packages we have installed using the DocMaker utility, which comes with BEAST2.

Open a terminal and navigate to the directory where you want to save the BEAST2 XML manual

• Type <beast2 path>/bin/applauncher DocMaker . where <beast 2 path> should be replaced with the directory where BEAST2 is installed. For instance, if you’re using a Mac and you installed BEAST v2.7.4 in the default location, you would need to type /Applications/BEAST\ 2.7.4/bin/applauncher DocMaker .
• Now open the newly generated index.html in any browser.

This is also documented here

The generated documentation should be for the version of BEAST2 that is installed and contain XML documentation for all packages that are installed. Note that while this documentation is extremely useful, it can still be very sparse for most components since most developers don’t invest a lot of time in documentation. Most BEAST2 packages come with some example XML files and these can also be very useful for figuring out how to specify models that cannot be specified in BEAUti. You can locate the directory where a package (and its example XML files) is installed from BEAUti by navigating to File > Set working dir and selecting a package. If you then try to open a file BEAUti will open in the directory where that package is installed.

Error messages not covered in this tutorial

Many different issues can occur in BEAST2, and it is impossible to cover them all in this tutorial. However, one important thing to keep in mind is that BEAST2 will always attempt to provide some information on the issue it has encountered. Thus it is critical to carefully read the error messages, as in all of the examples in this tutorial. While the error messages may not always be very insightful, they usually contain enough information to solve most common issues.

For the issues that cannot be easily debugged it is recommended to contact the package developers, or to make a post on http://groups.google.com/group/beast-users. If it is a common issue it is likely that someone else has encountered it before you!

In the rare case where BEAST2 initializes an analysis without any problems and then subsequently crashes it is likely that there are issues with the code (contact the developers) or with your setup (try running it on a different machine).

Acknowledgment

The complex parameter issue example in this tutorial was inspired by a real issue encountered during the analysis of the convergent evolution of true crabs (Wolfe et al., 2022).

Useful Links

• Bayesian Evolutionary Analysis with BEAST 2 (Drummond & Bouckaert, 2014)
• BEAST 2 website and documentation: http://www.beast2.org/
• BEAST 1 website and documentation: http://beast.bio.ed.ac.uk
• Join the BEAST user discussion: http://groups.google.com/group/beast-users
• BEAST 2 XML documentation and how to compile it for your own setup: http://www.beast2.org/2023/06/01/docmaker.html
• Some common reasons why BEAST 2 may fail to find a valid initial state: http://www.beast2.org/2018/07/04/fatal-errors.html

Relevant References

1. Bouckaert, R., Heled, J., Kühnert, D., Vaughan, T., Wu, C.-H., Xie, D., Suchard, M. A., Rambaut, A., & Drummond, A. J. (2014). BEAST 2: a software platform for Bayesian evolutionary analysis. PLoS Computational Biology, 10(4), e1003537. https://doi.org/10.1371/journal.pcbi.1003537
2. Bouckaert, R., Vaughan, T. G., Barido-Sottani, J., Duchêne, S., Fourment, M., Gavryushkina, A., Heled, J., Jones, G., Kühnert, D., Maio, N. D., Matschiner, M., Mendes, F. K., Müller, N. F., Ogilvie, H. A., Plessis, L. du, Popinga, A., Rambaut, A., Rasmussen, D., Siveroni, I., … Drummond, A. J. (2019). BEAST 2.5: An advanced software platform for Bayesian evolutionary analysis. PLOS Computational Biology, 15(4).
3. Wolfe, J. M., Ballou, L., Luque, J., Watson-Zink, V. M., Ahyong, S. T., Barido-Sottani, J., Chan, T.-Y., Chu, K. H., Crandall, K. A., Daniels, S. R., Felder, D. L., Mancke, H., Martin, J. W., Ng, P. K. L., Ortega-Hernández, J., Theil, E. P., Pentcheff, N. D., Robles, R., Thoma, B. P., … Bracken-Grissom, H. D. (2022). Convergent adaptation of true crabs (Decapoda: Brachyura) to a gradient of terrestrial environments. BioRxiv. https://doi.org/10.1101/2022.12.09.519815
4. Drummond, A. J., & Bouckaert, R. R. (2014). Bayesian evolutionary analysis with BEAST 2. Cambridge University Press.

Citation

If you found Taming the BEAST helpful in designing your research, please cite the following paper:

Joëlle Barido-Sottani, Veronika Bošková, Louis du Plessis, Denise Kühnert, Carsten Magnus, Venelin Mitov, Nicola F. Müller, Jūlija Pečerska, David A. Rasmussen, Chi Zhang, Alexei J. Drummond, Tracy A. Heath, Oliver G. Pybus, Timothy G. Vaughan, Tanja Stadler (2018). Taming the BEAST – A community teaching material resource for BEAST 2. Systematic Biology, 67(1), 170–-174. doi: 10.1093/sysbio/syx060
